Type and size of rivets for cleat at lower mast

Contacted them and they sorted me out - much better than the original solution!

12/06/2023 11:37:00
SSJTennis66
Posts: 8

Because you want a thin slightly stretchy line between the upper ceat and the lower. Otherwise as the mast bends and straightens you tend to pull it out of the top cleat and the sail drops a bit. Also don't want windage of a thicker rope. You should be able to have a knot (or splice) that goes easily thru the top of the mast.

05/06/2023 11:58:00
gk.griffiths
Posts: 186

Thanks, Peter and well done last week BTW

02/06/2023 16:10:00
SSJTennis66
Posts: 8

SSJTennis/Mike,
See here re main halyard;
https://www.rsaerosailing.org/index.asp?p=forum&fid=2&tid=8989
https://www.rsaerosailing.org/index.asp?p=forum&fid=13&tid=10262

02/06/2023 11:51:00
Posts: 0

Thanks, Matt - I will give them a call - still wondering why no-one uses a straight through length of the same diameter rope though - any ideas? Mike

02/06/2023 10:51:00
SSJTennis66
Posts: 8

'This would avoid the rigmarole of tugging the knot through the hole at the top of the mast ...'

Most of the sailors in our club (including me) use a spliced halyard instead of the OEM knotty version. The club chandlery (https://sandypointwatersports.com/) usually keeps a few in stock; I'm sure other suppliers have them as well.

02/06/2023 08:03:00
[email protected]
Posts: 25

Thanks for posting this - we've been wondering why the halyard is not holding and this could well be the issue.

As a 'newbie' to this... can I now ask the stupid question? And apologies if this has been asked and answered many times before, but I could not find it in the threads. Has anyone swapped the standard halyard set up for a continuous length of (e.g) 4mm rope? This would avoid the rigmarole of tugging the knot through the hole at the top of the mast and make it easier to cleat off. I am sure that there must be an obvious answer as to why this is not done but.....

Any advice much appreciated!

Thanks

01/06/2023 11:19:00
SSJTennis66
Posts: 8

I will use a box column drill for the wholes. If There will be a damage, I would put Epoxid and for sealing Sikaflex in the whole.

15/05/2023 17:35:00
mheber
Posts: 76

Thank you Michael.

On a related subject, I get nervous drilling out rivets in carbon spars. I've done it and it's been successful but it scares me that I may cause some damage.

Are they any specific techniques recommended and / or should I just not be too worried about drilling when there's carbon around the rivet?

Thanks

15/05/2023 10:56:00
Hairsy
Posts: 46

Very quick, clear and good answer, very nice also to see the Catalogue, which is a very helpfull tool, I did not know up to now.

See the answer below:

Good morning Michael,

Thank you for your email,

The rivets used for the attaching the cleat are 4.8 x 19.7 rivets - https://www.rssailingstore.com/Catalogue/Dinghy-Chandlery/RS-Fixings/Rivets/Carbon/Rivet-Carbon-48-x-197-FIX-R48-C18 - they are stainless steel rivets.

To help identify the fixings required we have put together some exploded diagrams which shows the fittings and the fixings required for each one: https://www.rssailingstore.com/Catalogue/RS-Parts/RS-Aero/Masts-Parts - in this diagram they are number 14 for the rivets and the cleat is number 24.

I hope this helps,

15/05/2023 10:21:00
mheber
Posts: 76

Dear Peter,

Mail was just sent out, waiting for an answer. Once I get an answer, I will post it here.

Best regards

Michael

14/05/2023 19:06:00
mheber
Posts: 76

Hi Michael,
I suggest you ask [email protected] and report back here.

14/05/2023 17:15:00
Posts: 0

The cleat at the lower mast section for the main Halyard of our Aero is worn out.
It is fixed with rivets in the Carbon.

What type and size of rivets have to be used in Carbon?
Stainles Steel, Aluminium?
And what size ist the rivet, it seems to me 4 mm diameter (not sure), but what length?

Has anybody experience or specifiactions?

Best regards

Michael

13/05/2023 09:28:00
mheber
Posts: 76
